Reach Stacker Rau Thawv Chaw Nres Khoom
Reach Stacker rau Thawv Chaw Nres Khoom
Lub ncav cuag stacker muaj retractable thiab sab laug-txoj cai rotating thawv spreaders, uas yuav siv tau rau 20 ko taw thiab 40 ko taw thawv loading thiab unloading ua hauj lwm. Thaum lifting ntim, ncav cuag stacker tsis tas yuav perpendicular rau lub thawv, tab sis tuaj yeem ua haujlwm ntawm lub kaum sab xis nrog lub thawv. Tom qab lifting, lub spreader tuaj yeem tig mus dhau ntawm qhov nqaim channel. Nyob rau tib lub sijhawm, tus kis tau tuaj yeem txav tau los ntawm 800mm ntawm sab laug thiab sab xis, txhawm rau pab txhawb kev sib dhos ntawm lub thawv thaum lub sijhawm hoisting thiab txhim kho kev ua haujlwm zoo. Rau qhov chaw nres tsheb thauj khoom nrog qhov chaw tsis zoo, lub crane pem hauv ntej tuaj yeem ua haujlwm ib txwm.
Lub telescopic boom tuaj yeem thauj khoom thiab luffed. Kev tshem tawm thiab tsaws ntawm lub thawv yog ua tiav los ntawm boom telescopic thiab luffing. Thaum lub boom txuas ntxiv thiab lub suab lub tog raj kheej txuas ntxiv, nws qhov nrawm nrawm nrawm dua. Thaum nws txo qis, nws raug kaw tib lub sijhawm kom tau txais kev txo qis dua. Thaum lub sijhawm ua haujlwm, tag nrho lub tsheb taug kev, luffing thiab boom telescopic ua haujlwm tuaj yeem pom tau tib lub sijhawm, nrog rau kev ua haujlwm siab.
| Cav | ||
| Hom | CUMMINS | |
| Hom | QSM 11 | |
| Lub tog raj kheej no./displacement | 6/10820 cm3 | |
| Rated zog @ ntsuas ceev | 250kw @ 2100rpm | |
| Max. lub zog | 1674 Nm @ 1500 rpm | |
| Rated tam sim no ntawm alternator | 150A | |
| Roj teeb | 24V | |
| Kev xa tawm | ||
| Hom | ZF/5WG261 AUTO | |
| Hom | Auto-shift/interlock | |
| Hom Clutch | Torque converter | |
| iav no. | 5F/3R | |
| LUB SIJ HAWM | ||
| Tsav lub log | 18. 00-25 40PR | |
| Steering log | 18. 00-25 40PR | |
| Hom | Pneumatic | |
| Siab | 10 bar | |
| Quantity, pem hauv ntej / nram qab | 4/2 | |
| TANKS CAPACITY | ||
| Hydraulic roj tank | L | 800 |
| Roj tank | L | 500 |
| DRIVE AXLE | ||
| Hom | Kessler/Lub teb chaws Yelemees | |
| Qauv | D102PL341 | |
| STEERING AXLE | ||
| Hom | Kessler/Lub teb chaws Yelemees | |
| Qauv | L102 | |
| Steering | Ob chav ua lub tog raj kheej | |
| BRAKE SYSTEM | ||
| Kev pabcuam nres | Hydraulic ntub-disc | |
| Nres nres | Hluav taws xob tso tawm disc nres, enabled thaum fais fab tuag | |
| BOOM | ||
| 2 x Dual nkaus nqa lub tog raj kheej | ||
| 1 x Dual action extension cylinder | ||
| SPREADER | ||
| Tswj ISO 20'-40' thawv | ||
| 2 x damping cylinder | 2 x gearbox & nres system | |
| Hom | SIB 45 | |
| Hloov cov degrees | -105 degree / ntxiv rau 195 degree | |
| Sideshift | -800/ ntxiv rau 800mm | |
