SOCMA 10ton Lithium Roj Teeb Hluav Taws Xob Forklift

Cov roj teeb hom: lithium hlau phosphate, Lub cev muaj zog hom: cov hlau nplaum ruaj khov synchronous lub cev muaj zog / daim npav muab lub cev muaj zogSteering hom: tag nrho hydraulic steering, lub zog muaj peev xwm, nres lub zog rov qab siv zog: 7 -9 teev tom qab them tag nrho tuaj yeem lav nrog lub peev xwm loj lithium roj teeb

Xa kev nug

Khoom Taw qhia

Battery warranty: 5 years or 4000（2800） charge and discharge (battery attenuation is not more than 30 percent )

Lub cev muaj zog thiab hluav taws xob tswj warranty: 3 xyoos

Hydraulic and Mechanical Transmission warranty: 1 year and（or） 2000 hours. During the warranty period, if the vehicle has a non-human fault. After seller confirm and approve,it is the seller's responsibility to provide the necessary accessories and technical

Parameter

Nta
● High security -- Lub zeem muag dav mast muab qhov pom kev pom hauv ntej, raug tshem tawm ntawm cov khoom. Grille ru tsev tiv thaiv muab qhov pom zoo sab saud rau cov neeg tsav tsheb; -- Standardized LED teeb, siab ci, lub neej ntev, txuag hluav taws xob thiab kev tiv thaiv ib puag ncig.
● High comfort -- Standard me me txoj kab uas hla lub kauj, lub teeb tswj, txo tus neeg tsav tsheb qaug zog; -- Cov khoom siv xim sib xyaw ua ke muaj zog tib neeg- tshuab kev sib cuam tshuam thiab raws sij hawm thiab tawm tswv yim kom raug lub tsheb khiav; -- Qhov chaw tswj dav dav, lub rooj zaum xis, txaus siab rau kev caij tsheb.
●Rich options --High tso pa tawm, cua prefilter, fireproof cap, khoom log, ob theem free nqa mast, peb theem free nqa mast, widening diav rawg ncej, diav rawg tes tsho, sab shifter, ntawv yob clamp, bale clamp, thawv clamp, thaiv clamp, rotators, nruas clamp, thawb- rub, thiab lwm yam.
Kev ua tau zoo
Basic Parameter	Qauv	HNF 100-EL
	Lub zog	Lithium roj teeb ntshiab hluav taws xob
	Hom neeg ua haujlwm	Tus Tsav Tsheb / Lub Rooj
	Rated peev	10, 000kg
	Chaw thau khoom	600mm
	Wheelbase	2 850mm
Qhov hnyav	Tsheb hnyav	14,500 Kg
Tire, Chassis	Hom log tsheb	Pneumatic / Khoom (yeem)
	Tyre Specs (pem hauv ntej)	9.00-20.16 dr hab
	Tyre Specs (rov qab)	9.00-20.16 dr hab
	Tyre tooj (pem hauv ntej / nram qab, x= tsav log)	4x/2
	Log tread pem hauv ntej	16 90mm
	Log tread rear	1960 hli
Basic Dimension	Mast Tilting Angle (Fwd/Bwd)	6 degree / 12 degree
	Mast qhov siab ( diav rawg qis)	2, 850mm
	Mast lifting qhov siab	3, 000mm
	Max. nqa qhov siab	4, 360 mm
	Qhov siab mus cab	2, 850mm
	Zuag qhia tag nrho ntev (nrog diav rawg)	5, 610 mm
	Length rau diav rawg nto (tag nrho ntev yam tsis muaj diav rawg)	4, 410 mm
	dav dav	2,250 mm
	Fork Size (LWT)	1,20018080mm
	Fork carriage dav	2,200 hli
	Fork opening range	250-1750 hli
	Mast av clearance	210 hli
	Wheelbase center min av clearance	310 hli
	Txoj kab uas hla (sab nraum)	5000 hli
Parameter	Kev ceev ceev (load / unload)	16/20 km / teev
	Max. lifting qhov siab (load / unload)	220/270 hli/s
	Max. txo qhov ceev (load / unload)	340/320mm/s
	Traction	Greater than or equal to 56 kN
	Qib muaj peev xwm (load)	Ntau dua lossis sib npaug li 20 feem pua
	Tsav nres	Clamp disc (yeem)
	Nres nres	Clamp disc caij nplooj ntoos hlav nres
Roj teeb	Hom roj teeb	LiFePO
	Roj teeb ntsuas qhov peev xwm	144 kWh 141 kWh
	Rated muaj peev xwm ntawm roj teeb	228 AW Ah
	Rated voltage	618 V
	Rounds ntawm tag nrho cov nqi thiab tawm mus	More than 40002800 times
	Theoretical kev pab lub neej	>8 years
	Them sij hawm	1-2h（Variance with the charger） 1.0 h （SOC 20 percent -100 percent 120kW charger）
	Kev siv fais fab	12-16 kWh/h （based on standard forklift working condition）
Driving system	Hom lub cev muaj zog	Permanent magnet synchronous lub cev muaj zog
	Lub cev muaj zog	90 kW ua
	Kev sib kis	Motor direct drive
Hydraulic system	Hom lub cev muaj zog	Permanent magnet synchronous lub cev muaj zog
	Lub cev muaj zog	74 kW ua
	Siab	20 MPa
Steering system	Steering iav qauv	Full hydraulic steering
	Siab	14 MPa
	Steering hom	Kab rov tav cylinder kauj
