25 tuj forklift
| Yam khoom | Yam lus | Chav tsev | |
| HNF-250 | |||
| Nta | Rated Load | Q (t) | 25 |
| Load center | c (hli) | 1250 | |
| Wheelbase | y (hli) | 4400 | |
| Nyhav | Nyhav | kg | 35000 |
| Chassis | Tire Specs.:Front | 14.00-24-28PR | |
| Tire Specs.:Rear | 14.00-24-28PR | ||
| Tires Qty, pem hauv ntej / nram qab (lub log x-tsav) | 4 \ / 2 | ||
| Log tread: Pem hauv ntej | b10 (hli) | 2200 | |
| Log tread: Tsheb | b11 (hli) | 2390 | |
| Dimension | Mast / carriage qaij kaum sab xis (pem hauv ntej / nram qab) | Kawm tiav (°) | 6 \ 12 |
| Mast qhov siab (diav rawg) | h1 (hli) | 3860 | |
| Mast lifting qhov siab | h3 (hli) | 3500 | |
| Max.lifting qhov siab | h4 (hli) | 5610 | |
| Qhov siab tshaj rau tus neeg saib xyuas lub taub hau (qhov siab kom nres) | h6 (hli) | 3510 | |
| Tag nrho qhov siab (nrog rab rawg) | l1 (hli) | 9190 | |
| Diav qaum zaum ntsug nto rau sab nram qab kawg ntawm lub tsheb | l2 (hli) | 6745 | |
| Qhov dav dav | b1 / b2 (hli) | 3050 | |
| Fork qhov ntev | s / e (hli) | 2440X300X110 | |
| Diav laub carriage dav | b3 (hli) | 3060 | |
| Mast av hauv av (nrog rau kev thauj) | m1 (hli) | 300 | |
| Wheelbase center min av hauv av (nrog load) | m2 (hli) | 420 | |
| Min.Turning radius | Wa (hli) | 6700 | |
| Mus ncig teb chaws ceev (nrog load / tsis muaj load) | km / h | 25/29 | |
| Kev ua tau zoo | Max.lifting ceev (nrog load / tsis muaj load) | mm / s | 260/270 |
| Max.Lawing speed (nrog load / tsis muaj load) | mm / s | 315/260 | |
| Traction | N | 17000 | |
| Gradeablity (nrog load / tsis muaj load) | % | 20/21 | |
| Tsav nres | Hydraulic clamp disc | ||
| Cav hom / qauv | Xaiv ib qho | Weichai cav | |
| Cav | WP10G220E343 9.726L 162KW 2000rpm | ||
| Yeem xaiv ob | Dongfeng Cummins | ||
| QSC8.3-C240 8.3L 179KW 2200rpm | |||
| Kheej Kheej | 6 | ||
| Lwm tus | Kis zog (Pem hauv ntej / nram qab) | 2 \ / 1 | |
| Attachments ua haujlwm siab | bar | 180 | |
| Attachments siv cov roj | l / min | 80 |
1, txais Cummins, Weichai, Yuchai turbocharging engine, haib, kev txuag hluav taws xob, kev tiv thaiv ib puag ncig, txaus siab qhov yuav tsum tau ua haujlwm ntawm kev ua haujlwm siab.
2, siv Hangchi, Sanchi planet hom hydraulic zog ua haujlwm kis loj, traction loj nyob rau hauv kev koom tes nrog kev khiav hauj lwm mob, kev sib kis kab mob ntau txhim khu kev qha.
3, txais yuav ob chav turbine hydraulic torque converter, hloov ceev tsis pauv, muaj zog rau kev hloov ceev, yooj yim rau kev khiav hauj lwm.
4, Hloov tau qhov sib npaug ntawm kev tswj ceev uas sib npaug nrog lub nruab nrab nruab nrab, lub tshuab pib ruaj ntseg ntxiv.
5, pem hauv ntej axle txais kev hnyav hom tsav qauj, loj loj ntawm qaum tsev, hub thiab kev coj tus kheej, kauv khi iav thiab log log log log deceleration nce twist, steel qauv bridge plhaub txhawb, nce lub peev xwm thiab kev pab cuam lub neej.
6, Tsis muaj cov phaj hom xov, ua rau lub peev xwm ntawm hub.
7, rear qav los ntawm transverse hydraulic lub tog raj kheej hom steering, lub siab qis muaj compact qauv, kis kaum sab xis yog 70.5 ° , pab txo qhov kev ua haujlwm thiab txo lub laub hnav thiab txhim kho kev tsav tsheb.
8, siv plaub lub caliper disk brake, lub plhaub tawg paj, lub tshuab huab cua nram qab, 18 lub sij hawm siv lub zog siab zog, cov cua kub ceev, kev ruaj ntseg thiab kev nyab xeeb
9, hydraulic thauj sensing kauj system, rear lub qes qes nrog me me voj voog voog, saj zawg zog thiab lub teeb kauj
10, yuav siv ob chav twj tso kua mis ua haujlwm ua haujlwm hydraulic, zoo heev txo roj noj, zog noj. Hydraulic system nruab nrog roj radiator thiab nraub qaum ceev tiv thaiv ntaus, xyuas kom lub tshuab tshuav kub kub
11, siv kev txwv kev tswj ceev thiab lub tshuab fais select valve, txo qhov kev cuam tshuam ntawm qhov hydraulic, txo qis mast mus rau hauv av thaum tshuab hluav taws tawm
12, koom tes nrog hercynian lub koomhaum Suav Academy ntawm "kev teeb tsa ua qauv zoo tshaj plaws", xyuas qhov kev sib koom siab thiab kev ua kom muaj zog, qaug zog lub neej kev twv ntawm lub forklift, cov caij nyoog muaj kev sib txuas ntawm cov khoom sib tsom, kev tsim qauv tsim, kom muaj kev ruaj ntseg ntawm cov khoom siv
12.1, txais yuav ntev wheelbase, thawv ob chav nqaj ncej, muab tau zoo rigidity thiab lub zog, kom muaj kev ntseeg siab ntawm forklift tsheb chassis
12.2, sab hauv thiab sab nraud txais yuav cov menyuam ua haujlwm, lub qhov rooj ncej nrog cov menyuam, cov phiajcais ntawm lub zog ua haujlwm, kev pabcuam ntev ntawm lub siab, kev ruaj siab
12.3, mast lifting qhov siab yuav nce mus txog 3 meters, siab mast, qis mast, txheem mast thiab ntau yam accessories yuav tsum fitteed raws li cov neeg yuav tsum tau
12.4, tau txais kev kho mob ceev ceev, hloov sai sai. Hydraulic diav rawg, yooj yim los kho. Cascade siab zog nkhaus, ntau hnav tsis taus, tuaj yeem ua haujlwm rau lub neej
13, nrog kev sib zog hnyav forklift log tsheb loj, rear lub tsheb qis ua viav vias nyob hauv nruab nrab, muaj kev sib tw ua kom zoo thiab kev ua tau zoo.
14, sib npaug nrog kev kho kom haum, cov neeg seev cev, kev sib koom tes tswj kev sib faib khoom thiab kev ua hauj lwm, kev tswj tau yooj yim thiab yooj yim
15, siv cov hluav taws xob zoo hauv hluav taws xob, roj teeb uas tsis muaj txawb, cov xaim hluav taws xob ua haujlwm tsis zoo, ruaj khov thiab ruaj khov. Alarm matched wiht ntxuam, radios, cua txias, reversing zaub, tuaj yeem phom nrog lub tshuab hnyav raws li cov neeg xav tau.
16, tag nrho tshuab zoo nkauj thiab tus. Khoom kim heev dav saib, nrog rau lub voj voog, suab nrov nrov, zoo sealing
17, domestication qhov chaw, standardization, nqi-zoo, seem seemality zoo yooj yim, kev tu txhua hnub yog yooj yim thiab ceev.
18. siv dav dav hauv airports, cov chaw nres nkoj, cov chaw nres tsheb, cov chaw, cov chaw cia khoom thiab lwm yam kev siv ua haujlwm loj rau kev thauj khoom thiab tshem tawm, cov tsheb thauj khoom thiab luv luv
Cim npe nrov: 25 tuj forklift, Tuam Tshoj, manufacturers, hoobkas, customized & 12ton-50t forklift
