2 Tuj Electric Rider Stacker
video

2 Tuj Electric Rider Stacker

Qhov Loj: 2410mm1410mm2246mm
Loading tus nqi: 2000kg
Lub Sijhawm Lead: 30 hnub
OEM tau txais, koj daim ntawv lo, daim ntawv lo, logo
Xa kev nug
Khoom Taw qhia



Docks, tshav dav hlau, warehouses, chaw tsim kho, freight yards, thiab lwm qhov chaw nquag siv hluav taws xob thauj aircraft. Cov tsheb thauj mus los, tseem hu ua tsheb thauj khoom, yog cov tsheb tsis siv neeg siv los ntawm kev lag luam luv luv - kev thauj mus los deb, nrog rau kev thauj khoom, tshem tawm, thiab ntim khoom. Nov yog qee qhov zoo ntawm kev siv hluav taws xob conveyors:

1. Thaum muab piv rau kev tuav tuav, tus nqi ncaj qha ntawm cov tsheb thauj khoom hluav taws xob tuaj yeem raug txo los ntawm ntau dua 25 feem pua, txo qis kev siv zog ntawm cov tsheb thauj mus los thiab txhim kho kev lag luam kev ua haujlwm.

2. Lub tshuab hluav taws xob nqa hluav taws xob yog qhov tsis raug, nrog cov lus teb ceev, kev tswj xyuas meej, thiab kev ua haujlwm ruaj khov.

3.Lub tsheb thauj khoom hluav taws xob suav nrog cov khoom thauj khoom thauj khoom thiab thauj khoom, txo cov sijhawm thauj khoom thiab thauj khoom.

4. Siv cov khoom siv hluav taws xob tuaj yeem tiv thaiv kev puas tsuaj rau cov khoom txav thiab ua kom cov khoom tiav.

5. Lub motorized conveyor tsa lub stacking qhov siab thiab maximizes muaj nyob stacking qhov chaw.

6. Lub tshuab nqa hluav taws xob muaj kev sib koom ua ke siab, nrog rau kev tiv thaiv ruaj khov rau tag nrho cov xov hlau thiab cables thiab tus nqi qis qis.

7. Vim tias lub tsheb thauj khoom hluav taws xob muaj kev txav mus los zoo heev thiab muaj peev xwm ua haujlwm loj, nws txo qis qhov xav tau ntawm kev thauj khoom thiab thauj khoom ntxiv thaum tseem txo nqi tag nrho ntawm kev thauj khoom thiab thauj khoom.

8. Lub tshuab nqa hluav taws xob muaj ntau yam thiab muaj kev nyab xeeb. Txhawm rau tua tag nrho cov hluav taws xob thiab nres hluav taws xob thaum muaj xwm txheej ceev, thawb lub khawm nres thaum muaj xwm ceev.

2 Ton Electric Rider Stacker (2)

Qauv: CQDH20C (ib txiab)

Tsav hom


roj teeb

Load peev / Rated load

Q (kg)

2000

Load center nrug

c (mm)

500

Load nrug, nruab nrab ntawm tsav qag diav rawg

x (mm)

334

Log tsheb loj, pem hauv ntej

mm

280x100 + 160x60

Log tsheb loj, rear

mim

125x82(4)

Log, tus lej pem hauv ntej rear (x=driven log)


1 ua plus2

Tilt ntawm mast / diav rawg carriage rau pem hauv ntej / rov qab)

Qib

2/5

Qhov siab, mast qis

h1 (mm)

2125 2375 2625

Free nqa

h2 (mm)


Max. nqa qhov siab

h3 (mm)

3000 3500 4000

Qhov siab, mast ncua

h4 (mm)

3881 4381 4881

Qhov siab ntawm kev tiv thaiv saum taub hau

h6 (mm)

2246

dav dav

b1 / b2 (mm)

1310/1040

Zuag qhia tag nrhol lajth

1 (mm)

2409

Ntev mus rau lub ntsej muag ntawm rab rawg

12 (mm)

1339

Fork dimension

s/e/l (mm)

35/100/1070

Mus txog deb

I4 (mm)

500

Fork qhov siab, qis dua

h8 (mm)

35

Distance of "X"(see above diagram)

mm

450

Patent rau cov qauv siv hluav taws xob:

1. Lub tshuab hluav taws xob forklift lub zog rov ua haujlwm raws li kev sib txuas ntawm ntau- hydraulic motors thiab accumulators;

2. Kev sib xyaw ua ke hluav taws xob forklift lub zog rov qab thiab rov siv dua.

2 Ton Electric Rider Stacker (1)2 Ton Electric Rider Stacker (4)

1. Peb lub tuam txhab

PNE (Fujian Southchina Heavy Machinery Manufacture Co., Ltd.) was established in 2010 with the goal of researching and developing material handling and construction machinery. The following are the current product lines:

1. Cov khoom siv tuav, xws li hnyav- lub luag haujlwm forklift, ntxhib - av forklift, telescopic forklift, lub cub tawg - them thiab cub taws - tsheb thauj khoom, crane forklift, thiab lub thawv ncav cuag stacker, rau npe ob peb.

2. siv tshuab, xws li lub log excavator lossis lub log loader

3. cov khoom rau lub zog tshiab kev taw qhia, xws li lithium roj teeb hluav taws xob crawler excavator / log loader, lithium roj teeb hluav taws xob log loader, thiab lithium roj teeb hluav taws xob hnyav- lub luag haujlwm forklift



2. Peb Qhov Zoo

Kev nyab xeeb thiab ruaj khov

l 1. Providing professional technical support.

l 2. Send the product catalog and instruction manual.

l 3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!

l 4. Personal call or visit are warmly welcome.

Sale of services:

l 1. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.

l 2. We guarantee punctuality, quality and quantities strictly implement the terms of contract... .

3. FAQ

Q: yog dab tsiPNE's general stance regarding after-sales service?



A: PNE offers a one-year or 2000-hour warranty on its devices, but company does not offer maintenance or repair to its customers. The end user's routine maintenance is the responsibility of the authorized local dealer. The maintenance would be completed by the end user customer or by a third-party workshop.
