16t Forklift Matched Nrog Knuckled Crane
Chaw taws teeb tswj crane
Cav: Cummins / Yuchai
Transmission: Hydraulic kis tau tus mob
Load Center: 900mm
Lifting qhov siab: 3500mm-6000mm
Mast hom: duplex dav pom mast, duplex dawb mast, triplex dawb mast
16t forklift turck nrog crane nyob tom qab
Load nkhaus ntawm crane
Hoisting txoj haujlwm orientation daim duab
Ntu A: Nws tuaj yeem ua haujlwm raws li 100 ntawm tus nqi ntawm kev nqa nqa kev ua haujlwm nkhaus.
Ntu B: Nws tuaj yeem ua haujlwm raws li 90 ntawm tus nqi ntawm kev nqa nqa kev ua haujlwm nkhaus.
Ntu C: Nws tuaj yeem ua haujlwm raws li 80 ntawm tus nqi ntawm kev nqa nqa kev ua haujlwm nkhaus.
Ntu D: Nws tuaj yeem ua haujlwm raws li 70 ntawm tus nqi ntawm kev nqa nqa kev ua haujlwm nkhaus.
Ntu E: Nws tuaj yeem ua haujlwm raws li 60 ntawm tus nqi ntawm kev nqa nqa kev ua haujlwm nkhaus.
Kev qhia tshwj xeeb ntawm SOCMA crane forklift HNFC160-1000
Muaj peev xwm
Yam khoom DESCRIPTION | UNIT | HNFC160-1000 |
| Q(t) | 16 | |
Chaw thau khoom | c (mm) | 900 |
Log puag | y (mm) | 3900 |
Qhov hnyav | kg | 28300 |
Tyre Specs.: Front | 12. 00x24/18PR | |
Tyre Specs.: Rear | 12. 00x20/18PR | |
Tyres Qty, front/rear (X-drive wheels) | 4/2 | |
Wheel tread: Front | b10 (mm) | 2060 |
Wheel tread: Rear | b11 (mm) | 2330 |
Mast / carriage qaij lub kaum sab xis (pem hauv ntej / nram qab) | degree | |
Mast qhov siab ( diav rawg qis) | mm | 3625 |
Max. nqa qhov siab | h3 (mm) | 3500 |
Zuag qhia tag nrho qhov siab ( diav rawg tsa) | h4 (mm) | 5375 |
Zuag qhia tag nrho ntev (nrog 1800mm diav rawg) | l1 (mm) | 8370 |
Fork pem hauv ntej ntsug nto mus rau nram qab kawg ntawm lub tsheb | l2 (mm) | 6570 |
Dav dav | b1 / b2 (mm) | 2750 |
Fork dimension | s/e/l (mm) | 110x220x1800 |
Fork carriage dav | b3 (mm) | 2750 |
Mast Min ground clearance (with load) | m1 (mm) | 265 |
Outrigger min av clearance (nrog load) | m2 (mm) | 450 |
Min. Tig lub vojvoog | Qhov (mm) | 7300 |
Travel speed (with load/without load) | km/h | 23/26 |
Max.lifting speed (with load/without load) | m/s | 270/300 |
Gradeablity (with load/without load) | feem pua | 15/20 |
Tsav tsheb nres | clamp disco nres | |
Cav hom / qauv | YC6J175-T302 | |
Hwj chim | KW | 129 |
Torque | rpm ua | 2200 |
Cua lub tog raj kheej | cm3 | 6 |
Txoj kev tsav tsheb | torque converter | |
Jib Weight | Kg | 17700 |
Tswj | Chaw taws teeb tswj | |
Outrigger Control | Manual landing valve tswj | |
Lub ntsiab Outrigger Longitudinal ncua | mm | 6276 |
Qhov deb nruab nrab ntawm kev ncua lub nraub qaum outrigger mus rau nruab nrab ntawm viav vias platform | mm | 1538 |
Distance between the center of additional extended outrigger at two sides | mm | 4178 |
Max. nqa qhov siab | mm | 17300 |
Ntxiv ceg extension / retraction ceev (tsis ua hauj lwm ceev) | S | 31/18 |
Main ceg extension / retraction ceev (tsis ua hauj lwm ceev) | S | 45/24 |
Rear leg extension/retraction speed (idle speed) | S | 16/8 |
Ntxiv kev txhawb nqa ceg / thim rov qab nrawm (tsis ua haujlwm nrawm) | S | 216/112 |
Main leg support / retraction speed (idle speed) | S | 237/128 |
Rear leg support / retraction speed (idle speed) | S | 38/20 |
Hook lifting/lowering (low speed) | S | W/Hook Fixed |
Hook lifting/lowering (high speed) | S | W/Hook Fixed |
Boom lifting/lowering (low speed) | S | 87/45 |
Boom lifting/lowering (high speed) | S | 63/37 |
Turn left/turn right (low speed) | S | 132/132 |
Turn left/turn right (high speed) | S | 108/108 |
Arm extension/retraction (low speed) | S | 235/126 |
Arm extension /retraction (high speed) | S | 278/145 |
Cov duab rau ntau txoj haujlwm crane forklift:
Fujian South Tuam Tshoj Heavy Machinery Manufacture Co., Ltd. yog mob siab rau kev tshawb fawb thiab kev tsim cov khoom siv tuav thiab siv tshuab.
Cov khoom lag luam tam sim no suav nrog:
1, cov khoom siv tuav xws li lub luag haujlwm hnyav xws li 15t forklift, 16t forklift, txog 50t forklift, rough terrain forklift, telescopic forklift, ncav cuag stacker.
2, kev tsim kho tshuab suav nrog lub log excavator, log loader.
3, telescopic slagging tsheb, uas yog customized siv nyob rau hauv cov hlau smelting kev lag luam.
Cov lus nug nquag nug rau SOCMA 15t diesel forklift
Dab tsi yog peb qhov zoo dua piv nrog lwm cov chaw tsim khoom / chaw tsim khoom?
Tus nqi sib tw-peb yog cov chaw tsim khoom tshaj lij thiab cov xa tawm loj tshaj plaws ntawm lub forklift hnyav hauv Suav teb. Los ntawm ntau qhov kev sib piv thiab kev tawm tswv yim los ntawm cov neeg siv khoom, peb cov nqi sib tw ntau dua li lwm cov tuam ntxhab / cov chaw tsim khoom.
Teb ceev- peb pab neeg no muaj ib pab neeg mob siab rau thiab txawj ntse, ua hauj lwm 24/7 los teb cov neeg nug cov lus nug thiab nug txhua lub sijhawm. Cov teeb meem tuaj yeem daws tau hauv 12 teev.
Kev xa khoom sai-rau ntau nws yuav siv sijhawm ntau dua 60 hnub rau cov chaw tsim khoom / lub Hoobkas los tsim cov tshuab xaj, thaum peb muaj ntau yam kev pabcuam, hauv zos thiab thoob tebchaws, kom tau txais cov tshuab raws sijhawm. Hauv 70 feem pua ntawm cov xwm txheej, peb tuaj yeem xa cov tshuab tsis tu ncua rau peb cov neeg siv khoom.
Ntev npaum li cas peb tus nqi rau lub luag haujlwm hnyav yuav siv tau?
Peb yog cov chaw muag khoom sib tw thiab tus phooj ywg, tsis muaj kev ntshaw ntawm cov nyiaj tau los. Yeej, peb tus nqi tseem nyob ruaj khov mus txog rau lub xyoo.
Peb tsuas yog kho peb tus nqi raws li ob qho xwm txheej:
Tus nqi ntawm USD: RMB sib txawv heev raws li kev sib pauv pauv nyiaj thoob ntiaj teb. Lub tuam txhab tau kho cov nqi tshuab, vim tias cov nqi zog nce ntxiv, thiab cov nqi raw khoom.
Yuav ua li cas logistics txoj kev peb tuaj yeem ua haujlwm rau kev xa khoom txog 15t forklift?
Peb tuaj yeem xa cov tshuab tsim kho los ntawm ntau yam khoom siv thauj mus los.
Rau 90 feem pua ntawm peb cov khoom xa tuaj, peb yuav mus los ntawm hiav txwv, mus rau txhua lub teb chaws loj xws li South America, Middle East, Africa, Oceania thiab Europe thiab lwm yam los ntawm lub thawv lossis RoRo / Bulk- cov khoom xa tuaj.
Rau cov tebchaws nyob ze ntawm Tuam Tshoj, xws li Russia, Mongolia, Kazakhstan, Uzbekistan thiab lwm yam, peb tuaj yeem xa cov tsheb thauj khoom los ntawm txoj kev lossis kev tsheb ciav hlau.
Rau lub teeb khoom seem hauv kev thov ceev, peb tuaj yeem xa nws los ntawm kev pabcuam xa khoom thoob ntiaj teb, xws li DHL, TNT, UPS, lossis Fedex.
