SOCMA 1.8 Tuj Hluav Taws Xob Loader
ZERO EMISSION
1.8 TONS Load peev xwm
A/C
CE CERTIFICATE
8 teev ua hauj lwm lub sij hawm ib zaug them
SOCMA Siv Lub Tshuab Log Loader 1.8 Tuj Rated Load
SOCMA yog cov chaw tsim khoom siv tshuab hauv Suav teb. Peb cov khoom yog nrov rau cov neeg siv khoom thoob plaws ntiaj teb nrog kev ua haujlwm zoo, kev pabcuam thiab lwm yam. SOCMA muaj cov tshuab hluav taws xob ua tiav suav nrog loader, excavator, telahandler, forklift thiab lwm yam. Yog tias koj xav sim peb lub tshuab ua siab zoo hu rau peb.
Parameter Specification:
|
Kev ua tau zoo |
Parameter |
|
|
Basic parameter |
Hluav taws xob Consumption Rate |
10-15 km/h variance nrog kev ua haujlwm |
|
Loading Rate |
1800kg ib |
|
|
|
1.0m³ |
|
|
|
47kn ua |
|
|
Qhov hnyav ua haujlwm |
7 200kg |
|
|
Max.Dumping Qhov siab |
2230/2450 hli |
|
|
Dumping nrug 45 degree Angle |
975/850 hli |
|
|
Transmission System |
Hom kis kab mob |
Mechanical Transmission |
|
Hloov Gear |
Pem hauv ntej 2 / rear 1 |
|
|
Max.Speed of Forward II |
10 km / h |
|
|
Max.Speed of Forward II |
26 km / h |
|
|
Max.Speed ntawm rear I |
10 km / h |
|
|
Max.Speed of rear II |
26 km / h |
|
|
Gradeability |
30.50% |
|
|
Traction |
55kn ua |
|
|
Parameter ntawm Travel Motor |
Hom Tsav |
Pem manent Magnet Synchronous Tsav |
|
Tsav Rated |
57 kW ua |
|
|
Motor kev khiav hauj lwm efficiency ntau yam |
86%-98% |
|
|
Parameter ntawm Main Pump Motor |
Hom Tsav |
Permanent Magnet Synchronous Tsav |
|
Tsav Rated |
37.7 kWm |
|
|
Roj teeb |
Motor kev khiav hauj lwm efficiency ntau yam |
86%-98% |
|
Hom roj teeb |
LiFe PO |
|
|
Roj teeb ntsuas qhov peev xwm |
140.92 qw |
|
|
Rated Peev Xwm ntawm Roj Teeb |
228 AW |
|
|
Rated Voltage |
618.24V |
|
|
Rounds ntawm tag nrho cov nqi thiab tawm mus |
4000+ |
|
|
Theoretical Service Lub Neej |
tshaj 8 xyoo |
|
|
Them sij hawm |
0.6-.5h(Variance nrog lub Charger) |
|
|
Hydraulic System |
Siab |
16 MPa |
|
Tus nqi ntws |
150L / min |
|
|
Nce Sijhawm |
5s |
|
|
Tag nrho lub sijhawm voj voog |
10s |
|
|
Steering System |
Steering iav Model |
BZZ 5-E315C |
|
Siab |
15 MPa |
|
|
Steering Hom |
Ari culated ncej kauj |
|
|
Steering Angle |
± 32 degree |
|
|
Nres hom |
Tsheb nres |
Clamp disc nres |
|
nres cua siab |
12 MPa |
|
|
Nres Nres |
Clamp disc nres |
|
|
Dimension |
Tag Nrho Qhov Siab |
3 060mm |
|
Dav dav |
19 20 mm |
|
|
Zuag qhia tag nrho ntev |
6 300mm |
|
|
Wheelbase |
2250 hli |
|
|
Log Tread |
1500 hli |
|
|
thoob nrog |
2150 hli |
|
|
Av Clearance |
270 hli |
|
|
Tig Radius (sab nraud) |
Tsawg dua los yog sib npaug li 5800mm |
|
|
Txoj hauj lwm tsav tsheb |
Central |
|
|
Lub rooj tsav tsheb |
Sited |
|
|
Standard Tyres (Pneumatically) |
Nos.of Wheels |
F2/R2 |
|
Tsav Tsheb |
4 lub log tsav tsheb |
|
|
Qhov loj ntawm Tyre |
16/70-20PR |
|
Nyob rau hauv xyoo tas los no, lub zog tshiab tsheb tau qhia txog kev loj hlob tawg. Tsis yog tsuas yog cov tub rog tshiab hauv kev tsim tsheb tau nce nrawm, tab sis txhua lub tsheb loj thoob ntiaj teb kuj tau tsim tsheb hluav taws xob.
Hauv kev lag luam Tshuag, lub zog tshiab tsheb sector tau txais kev pom zoo tsis tau pom dua. Lub sijhawm lithium roj teeb loj Ningde tau nce siab tsis ntev los no, nrog rau kev lag luam tus nqi ntau dua 1.3 trillion yuan.
Txhua yam ntawm cov cim qhia tau hais tias nws tau dhau los ua qhov tsis tuaj yeem ua rau cov neeg caij tsheb hluav taws xob los hloov cov tsheb siv roj.
Hauv kev lag luam ntawm cov cuab yeej siv tshuab hluav taws xob, cov cuab yeej siv hluav taws xob tshiab tau siv ntau dua hauv kev tsuas, tsim hluav taws xob, kev thauj mus los thiab lwm yam lag luam vim kev txuag hluav taws xob thiab emission txo thiab tus nqi qis.
